MikroTik CCR1009-7G-1C-1S+PC

Price (incl. tax): 11,00 €

Price (excl. tax): 11,00 €

11,40 €
С вкл. данък

7x Gigabit Ethernet, 1x Combo port (SFP or Gigabit Ethernet), 1xSFP+ cage, 9 cores x 1GHz CPU, 2GB RAM, LCD panel, passive cooling desktop enclosure, SmartCard slot, RouterOS L6, PSU

12754
EAN: 4002888127547
Количество
Последна наличност

The new updated revision of CCR1009 is here. We attempted to combine all the customer feedback and best practice in CCR device manufacturing that we learned over the last three years, since the first CCR1009 devices were launched.

Important changes

No switch-chip - the device now features only fully independent Ethernet ports each with a direct connection to the CPU, allowing to overcome previous shared 1Gbit limitation from switch-chip ports and utilize full potential of CPU processing power on those ports.

Combo-port - a single 1Gbit software interface that has two hardware interfaces - a SFP cage and a Gigabit Ethernet port, allowing you to use any type of connection available to you. Port also allows to switch from one to another interface from software, or in event of disconnect, providing new, unique hardware fail-over feature.

100Mbps SFP support - this is our first device that supports 100BASE-LX/100BASE-SX/100BASE-BX fiber modules, as well as standard 1.25G SFP modules.

More throughput - due to how ports are connected to CPU, new CCR1009 models can achieve higher theoretical throughput.

This unit is equipped with passive cooling enclosure, two heat-pipes and a specially designed heat-sink, so its completely silent. It’s powered by an external 24v 2.5A AC/DC adapter and supports power redundancy if you also power it from the PoE input port.

Unit also includes a LCD touchscreen, smart card slot, microSD and a SFP+ port for 10G connections.

Lindy
12754
1 Артикул

Техническо описание

CPU
TLR4-00980
CPU core count
9
CPU nominal frequency
1 GHz
License level
Level 6
Operating system
RouterOS
Size of RAM
2 GB
Storage size
128 MB
Storage type
NAND
Tested ambient temperature
-20°C to 60°C
10/100/1000 Ethernet ports
7
PoE in
Passive PoE
DC jack input Voltage
18-57 V
PoE in input Voltage
18-57 V
Gigabit Combo ports
1
Number of DC inputs
2 (DC jack, PoE-IN)
Max power consumption
38 W
Max power consumption without attachments
33 W
Number of SIM slots
1 Smart card (Mini SIM)
Memory card type
microSD
Memory Cards
1
Serial port
RS232
Number of USB ports
1
SFP+ ports
1
USB slot type
microUSB type AB

Конкретни референции

EAN13
4002888127547
